With power ranging from 20W to 100W, these solar panels are a good choice for sustainable energy. With a corrosion-resistant aluminum frame and tempered glass surface, they ensure long-lasting durability in adverse weather conditions. Easy to install and maintain, these solar panels are ideal for off-grid systems, highway lighting, rural new energy, energy storage, etc., providing reliable energy independence while minimizing environmental impact.
Parameters
20W solar panel
Name | 20W Solar panel |
Max output power |
20W |
Max working voltage |
18V |
Max working current |
1.13A |
Open circuit voltage |
22.56V |
Short circuit current |
1.202A |
Dimension | 250*520*17mm |
Weight | 2.0kg |
30W solar panel
Name | 30W Solar panel |
Max output power |
30W |
Max working voltage |
18V |
Max working current |
1.66A |
Open circuit voltage |
21.6V |
Short circuit current |
1.87A |
Dimension | 460*395*25mm |
Weight | 2.4kg |
40W solar panel
Name | 40W Solar panel |
Max output power |
40W |
Max working voltage |
18V |
Max working current |
2.2A |
Open circuit voltage |
21.6V |
Short circuit current |
2.34A |
Dimension | 350*670*25mm |
Weight | 2.4kg |
50W solar panel
Name | 50W Solar panel |
Max output power |
50W |
Max working voltage |
18V |
Max working current |
2.42A |
Open circuit voltage |
24.48V |
Short circuit current |
2.57A |
Dimension | 670*430*25mm |
Weight | 2.4kg |
60W solar panel
Name | 60W Solar panel |
Max output power |
60W |
Max working voltage |
18V |
Max working current |
3.10A |
Open circuit voltage |
22.0V |
Short circuit current |
3.47A |
Dimension | 670*500*25mm |
Weight | 3.5kg |
80W solar panel
Name | 80W Solar panel |
Max output power |
80W |
Max working voltage |
18V |
Max working current |
4.10A |
Open circuit voltage |
24.0V |
Short circuit current |
4.59A |
Dimension | 700*670*25mm |
Weight | 4.85kg |
100W solar panel
Name | 100W Solar panel |
Max output power |
109W |
Max working voltage |
18.2V |
Max working current |
5.99A |
Open circuit voltage |
21.4V |
Short circuit current |
6.2A |
Dimension | 830*670*30mm |
Weight | 5.5kg |
